Machining capability, drawing first.

We take on job work across milling and turning operations. Where a requirement falls outside what we can machine in-house, we say so before quoting.

Core Capabilities

Precision Machining
& Engineered Components

01 Capability

Precision CNC Turning

CNC turning for the production of precision rotational components, supporting consistent machining requirements across automotive, valve, gear and industrial applications.

Suitable for

  • Automobile Components
  • Valve Components
  • Shaft & Bushes
  • Gear Components
  • Precision Turned Parts
  • Chuck Draw Bars
  • Chuck Back Planes
Process
CNC Turning, Grooving, Threading
Application
Rotational Components, Automotive Parts
Production
Production Batches, CNC Production Machining
Quality
Dimension Inspection, Drawing Based Quality Check, Final Inspection
CNC machine cutting a metal component.

01 CNC Turning

Request a Quote

Send drawings and quantities, we reply with questions or a quotation.

Machines & Equipment

Built Around
Capable Machines

Our machining capabilities are supported by equipment selected for dependable component production, repeatable processes and flexible job-work requirements.

Representative photograph of a vertical machining centre.

Machine 01

Process : Milling

Status : Active

01 Machine

Ace Micromatic 1060V Vertical Machining Center (BT40-VMC)

Vertical Machining Center

A versatile vertical machining center with 4-axis capability and high-speed spindle options for complex milling operations.

Control System
Fanuc 0i-MF Plus
Axis Configuration
4-Axis Dynamic Assembly (X, Y, Z + Rotary C/A Axis)
4th Axis Kit Details
200 mm Chuck with Matching Tailstock (Rotary Table)
Bed Size (Table)
1200 mm (X) × 650 mm (Y) (Custom wide-table configuration)
Travel X
1050 mm (Extended Longitudinal Travel)
Travel Y
600 mm (Cross Travel)
Travel Z
600 mm (Vertical Z-Head Travel)
Spindle Taper
BT-40 Spindle Taper (7/24 No.40)
Spindle Speed
60 – 8,000 RPM Belt Drive (Standard) Upto 12,000 / 15,000 RPM Direct Drive (Optional Die-Mold Kit)
Motor Power
11 / 15 kW (High-performance Fanuc AC Spindle Motor)
Repeatability
±0.01 mm
Tool Pockets (ATC)
24-Tool Twin-Arm Automatic Tool Changer

Installed-machine specifications are published only once verified on the machine; manufacturer catalogue figures are not presented as shop capability.

Manufacturing Journey

From drawing
to finished part.

  1. Step 01

    Drawing Overview

    Read the drawing by checking dimensions, tolerances, material, threads, surface finish, and GD&T symbols.

  2. Step 02

    Material Selection

    Material are arranged to the specifications customer provide, or mentioned in the drawing.

  3. Step 03

    Setup Planning

    Work-holding, tooling and the machining sequence are planned for the component.

  4. Step 04

    Machining Execution

    The component is machined on CNC, VMC or lathe depending on the operations required.

  5. Step 05

    Inspection & Quality Checking

    Dimensions are checked against the drawing before the batch is dispatched.

  6. Step 06

    Finishing & Packing

    Deburring, surface finishing, and secure packing ensure parts are ready for dispatch.

  7. Step 07

    Delivery & Repeat Orders

    Proven setups allow faster turnaround for repeat batches, ensuring consistency.

CNC machine cutting a metal component.
Request for Quote

Have a part in mind?
Let's machine it.

Send us your 2D drawing, 3D model or component details. We'll review the manufacturing requirements and get back to you regarding machining feasibility, material, quantity and quotation.
